IXFN36N110P

Wickmann / Littelfuse
In Stock: 103

Can ship immediately

Pricing:

Call for price or sumbit a RFQ

Quote It

Technical Details

  • Series:Polar™
  • Package:Tube
  • Part Status:Active
  • FET Type:N-Channel
  • Technology:MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss):1100 V
  • Current - Continuous Drain (Id) @ 25°C:36A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On):10V
  • Rds On (Max) @ Id, Vgs:240mOhm @ 500mA, 10V
  • Vgs(th) (Max) @ Id:6.5V @ 1mA



  • Gate Charge (Qg) (Max) @ Vgs:350 nC @ 10 V
  • Vgs (Max):±30V
  • Input Capacitance (Ciss) (Max) @ Vds:23000 pF @ 25 V
  • FET Feature:-
  • Power Dissipation (Max):1000W (Tc)
  • Operating Temperature:-55°C ~ 150°C (TJ)
  • Mounting Type:Chassis Mount
  • Supplier Device Package:SOT-227B
  • Package / Case:SOT-227-4, miniBLOC

Related Products


IXFN40N110P

MOSFET N-CH 1100V 34A SOT-227B

IXFN40N110P Datasheet

Call for price


IXFR20N100P

MOSFET N-CH 1000V 11A ISOPLUS247

IXFR20N100P Datasheet

Call for price


IXFR30N110P

MOSFET N-CH 1100V 16A ISOPLUS247

IXFR30N110P Datasheet

Call for price


IXFV12N120P

MOSFET N-CH 1200V 12A PLUS220

IXFV12N120P Datasheet

Call for price


IXFV12N120PS

MOSFET N-CH 1200V 12A PLUS220SMD

IXFV12N120PS Datasheet

Call for price


IXFV15N100P
