IXKP20N60C5

Wickmann / Littelfuse
In Stock: 126

Can ship immediately

Pricing:

Call for price or sumbit a RFQ

Quote It

Technical Details

  • Series:CoolMOS™
  • Package:Tube
  • Part Status:Active
  • FET Type:N-Channel
  • Technology:MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss):600 V
  • Current - Continuous Drain (Id) @ 25°C:20A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On):10V
  • Rds On (Max) @ Id, Vgs:200mOhm @ 10A, 10V
  • Vgs(th) (Max) @ Id:3.5V @ 1.1mA



  • Gate Charge (Qg) (Max) @ Vgs:45 nC @ 10 V
  • Vgs (Max):±20V
  • Input Capacitance (Ciss) (Max) @ Vds:1520 pF @ 100 V
  • FET Feature:Super Junction
  • Power Dissipation (Max):-
  • Operating Temperature:-55°C ~ 150°C (TJ)
  • Mounting Type:Through Hole
  • Supplier Device Package:TO-220AB
  • Package / Case:TO-220-3

Related Products


IXKP20N60C5M

MOSFET N-CH 600V 7.6A TO220ABFP

IXKP20N60C5M Datasheet

Call for price


IXKP24N60C5M

MOSFET N-CH 600V 8.5A TO220ABFP

IXKP24N60C5M Datasheet

Call for price


IXTA90N15T

MOSFET N-CH 150V 90A TO263

IXTA90N15T Datasheet

Call for price


IXTC110N25T

MOSFET N-CH 250V 50A ISOPLUS220

IXTC110N25T Datasheet

Call for price


IXTH102N20T

MOSFET N-CH 200V 102A TO247

IXTH102N20T Datasheet

Call for price


IXTH90N15T

MOSFET N-CH 150V 90A TO247

IXTH90N15T Datasheet

Call for price


IXTQ102N20T

MOSFET N-CH 200V 102A TO3P

Call for price


IXTQ90N15T

MOSFET N-CH 150V 90A TO3P

IXTQ90N15T Datasheet

Call for price


IXTV102N20T
