SI5447DC-T1-GE3
Vishay / Siliconix
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 20V 3.5A 1206-8
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet SI5447DC-T1-GE3 Datasheet
-
ECAD Model
- Share
In Stock: 178
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:TrenchFET®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:3.5A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):1.8V, 4.5V
- Rds On (Max) @ Id, Vgs:76mOhm @ 3.5A, 4.5V
- Vgs(th) (Max) @ Id:450mV @ 250µA (Min)
- Gate Charge (Qg) (Max) @ Vgs:10 nC @ 4.5 V
- Vgs (Max):±8V
- Input Capacitance (Ciss) (Max) @ Vds:-
- FET Feature:-
- Power Dissipation (Max):1.3W (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:1206-8 ChipFET™
- Package / Case:8-SMD, Flat Lead
