STP30NM50N
STMicroelectronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 500V 27A TO220-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet STP30NM50N Datasheet
-
ECAD Model
- Share
In Stock: 177
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:MDmesh™ II
- Package:Tube
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):500 V
- Current - Continuous Drain (Id) @ 25°C:27A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:115mOhm @ 13.5A, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:94 nC @ 10 V
- Vgs (Max):±25V
- Input Capacitance (Ciss) (Max) @ Vds:2740 pF @ 50 V
- FET Feature:-
- Power Dissipation (Max):190W (Tc)
- Operating Temperature:150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-220-3
- Package / Case:TO-220-3
