NTD4906NAT4G
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 30V 10.3A/54A DPAK
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 147
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:10.3A (Ta), 54A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):-
- Rds On (Max) @ Id, Vgs:5.5mOhm @ 30A, 10V
- Vgs(th) (Max) @ Id:2.2V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:24 nC @ 10 V
- Vgs (Max):-
- Input Capacitance (Ciss) (Max) @ Vds:1932 pF @ 15 V
- FET Feature:-
- Power Dissipation (Max):-
- Operating Temperature:-
- Mounting Type:Surface Mount
- Supplier Device Package:DPAK
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
