BSS205NL6327HTSA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 20V 2.5A SOT23-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet BSS205NL6327HTSA1 Datasheet
-
ECAD Model
- Share
In Stock: 115
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:OptiMOS™
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:2.5A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):2.5V, 4.5V
- Rds On (Max) @ Id, Vgs:50mOhm @ 2.5A, 4.5V
- Vgs(th) (Max) @ Id:1.2V @ 11µA
- Gate Charge (Qg) (Max) @ Vgs:3.2 nC @ 4.5 V
- Vgs (Max):±12V
- Input Capacitance (Ciss) (Max) @ Vds:419 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):500mW (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:SOT-23-3
- Package / Case:TO-236-3, SC-59, SOT-23-3
