RJK0328DPB-01#J0
Renesas Electronics America
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 30V 60A LFPAK
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet RJK0328DPB-01#J0 Datasheet
-
ECAD Model
- Share
In Stock: 114
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:60A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:2.1mOhm @ 30A, 10V
- Vgs(th) (Max) @ Id:2.5V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:42 nC @ 4.5 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:6380 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):65W (Tc)
- Operating Temperature:150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:LFPAK
- Package / Case:SC-100, SOT-669
