STW25N95K3

Technical Details

• Series:SuperMESH3™
• Package:Tube
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):950 V
• Current - Continuous Drain (Id) @ 25°C:22A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:360mOhm @ 11A, 10V
• Vgs(th) (Max) @ Id:5V @ 150µA

• Gate Charge (Qg) (Max) @ Vgs:105 nC @ 10 V
• Vgs (Max):±30V
• Input Capacitance (Ciss) (Max) @ Vds:3680 pF @ 100 V
• FET Feature:-
• Power Dissipation (Max):400W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:TO-247
• Package / Case:TO-247-3
