SFT1431-E
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 35V 11A TP
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet SFT1431-E Datasheet
-
ECAD Model
- Share
In Stock: 100
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):35 V
- Current - Continuous Drain (Id) @ 25°C:11A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):4V, 10V
- Rds On (Max) @ Id, Vgs:25mOhm @ 5.5A, 10V
- Vgs(th) (Max) @ Id:-
- Gate Charge (Qg) (Max) @ Vgs:17.3 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:960 pF @ 20 V
- FET Feature:-
- Power Dissipation (Max):1W (Ta), 15W (Tc)
- Operating Temperature:150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TP
- Package / Case:TO-251-3 Short Leads, IPak, TO-251AA
