AOC2423

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Obsolete
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):20 V
• Current - Continuous Drain (Id) @ 25°C:2A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):2.5V, 10V
• Rds On (Max) @ Id, Vgs:80mOhm @ 1A, 10V
• Vgs(th) (Max) @ Id:1.2V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:10 nC @ 10 V
• Vgs (Max):±12V
• Input Capacitance (Ciss) (Max) @ Vds:470 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):600mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:4-AlphaDFN (0.97x0.97)
• Package / Case:4-SMD, No Lead
