FL6L52060L
Panasonic
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 20V 2A WSSMINI6-F1
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet FL6L52060L Datasheet
-
ECAD Model
- Share
In Stock: 195
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:2A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):1.8 V, 4V
- Rds On (Max) @ Id, Vgs:120mOhm @ 1A, 4V
- Vgs(th) (Max) @ Id:1.1V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:-
- Vgs (Max):±10V
- Input Capacitance (Ciss) (Max) @ Vds:300 pF @ 10 V
- FET Feature:Schottky Diode (Isolated)
- Power Dissipation (Max):540mW (Ta)
- Operating Temperature:125°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:WSSMini6-F1
- Package / Case:6-SMD, Flat Leads
