SIA453EDJ-T1-GE3

Technical Details

• Series:TrenchFET®
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Obsolete
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):30 V
• Current - Continuous Drain (Id) @ 25°C:24A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):2.5V, 10V
• Rds On (Max) @ Id, Vgs:18.5mOhm @ 5A, 10V
• Vgs(th) (Max) @ Id:1.4V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:66 nC @ 10 V
• Vgs (Max):±12V
• Input Capacitance (Ciss) (Max) @ Vds:1900 pF @ 15 V
• FET Feature:-
• Power Dissipation (Max):3.5W (Ta), 19W (Tc)
• Operating Temperature:-50°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:PowerPAK® SC-70-6 Single
• Package / Case:PowerPAK® SC-70-6
