UPA2739T1A-E2-AY
Renesas Electronics America
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 30V 85A 8HVSON
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet UPA2739T1A-E2-AY Datasheet
-
ECAD Model
- Share
In Stock: 186
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:85A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:5.7mOhm @ 23A, 4.5V
- Vgs(th) (Max) @ Id:-
- Gate Charge (Qg) (Max) @ Vgs:153 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:6050 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):1.5W (Ta)
- Operating Temperature:150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:8-HVSON (5.4x5.15)
- Package / Case:8-PowerVDFN
