- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 600V 4A TO251A
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet AOI4T60 Datasheet
-
ECAD Model
- Share
In Stock: 161
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):600 V
- Current - Continuous Drain (Id) @ 25°C:4A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:2.1Ohm @ 1A, 10V
- Vgs(th) (Max) @ Id:5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:15 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:460 pF @ 100 V
- FET Feature:-
- Power Dissipation (Max):83W (Tc)
- Operating Temperature:-50°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-251A
- Package / Case:TO-251-3 Stub Leads, IPak
