IRFS7734-7PPBF

Technical Details

• Series:HEXFET®, StrongIRFET™
• Package:Tube
• Part Status:Discontinued at Digi-Key
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):75 V
• Current - Continuous Drain (Id) @ 25°C:197A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):6V, 10V
• Rds On (Max) @ Id, Vgs:3.05mOhm @ 100A, 10V
• Vgs(th) (Max) @ Id:3.7V @ 150µA

• Gate Charge (Qg) (Max) @ Vgs:270 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:10130 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):294W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:D²PAK (TO-263AB)
• Package / Case:TO-263-7, D²Pak (6 Leads + Tab), TO-263CB
