PHK04P02T,518
Nexperia
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 16V 4.66A 8SO
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet PHK04P02T,518 Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$0.26318
- 2,500$0.26318
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):16 V
- Current - Continuous Drain (Id) @ 25°C:4.66A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):2.5V, 10V
- Rds On (Max) @ Id, Vgs:120mOhm @ 1A, 4.5V
- Vgs(th) (Max) @ Id:600mV @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:7.2 nC @ 4.5 V
- Vgs (Max):±8V
- Input Capacitance (Ciss) (Max) @ Vds:528 pF @ 12.8 V
- FET Feature:-
- Power Dissipation (Max):5W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:8-SO
- Package / Case:8-SOIC (0.154", 3.90mm Width)
