NTMFS4C06NT1G-001
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 30V 11A/69A 5DFN
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet NTMFS4C06NT1G-001 Datasheet
-
ECAD Model
- Share
In Stock: 112
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:11A (Ta), 69A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:4mOhm @ 30A, 10V
- Vgs(th) (Max) @ Id:2.1V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:26 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1683 pF @ 15 V
- FET Feature:-
- Power Dissipation (Max):770mW (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:5-DFN (5x6) (8-SOFL)
- Package / Case:8-PowerTDFN
