RJK5002DPD-00#J2

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):500 V
• Current - Continuous Drain (Id) @ 25°C:2.4A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:5Ohm @ 1.2A, 10V
• Vgs(th) (Max) @ Id:-

• Gate Charge (Qg) (Max) @ Vgs:6.7 nC @ 10 V
• Vgs (Max):±30V
• Input Capacitance (Ciss) (Max) @ Vds:165 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):30W (Tc)
• Operating Temperature:150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:MP-3A
• Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
