CPH3360-TL-W
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 30V 1.6A 3CPH
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet CPH3360-TL-W Datasheet
-
ECAD Model
- Share
In Stock: 139
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:1.6A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):4V, 10V
- Rds On (Max) @ Id, Vgs:303mOhm @ 800mA, 10V
- Vgs(th) (Max) @ Id:2.6V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:2.2 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:82 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):900mW (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:3-CPH
- Package / Case:TO-236-3, SC-59, SOT-23-3
