AO4202_120
Alpha and Omega Semiconductor, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 30V 19A 8SOIC
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet AO4202_120 Datasheet
-
ECAD Model
- Share
In Stock: 148
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:19A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:5.3mOhm @ 19A, 10V
- Vgs(th) (Max) @ Id:2.3V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:35 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:2200 pF @ 15 V
- FET Feature:Schottky Diode (Body)
- Power Dissipation (Max):3.1W (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:8-SOIC
- Package / Case:8-SOIC (0.154", 3.90mm Width)
