SI8469DB-T2-E1
Vishay / Siliconix
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 8V 4.6A 4MICROFOOT
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet SI8469DB-T2-E1 Datasheet
-
ECAD Model
- Share
In Stock: 132
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:TrenchFET®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):8 V
- Current - Continuous Drain (Id) @ 25°C:4.6A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):4.5V
- Rds On (Max) @ Id, Vgs:64mOhm @ 1.5A, 4.5V
- Vgs(th) (Max) @ Id:800mV @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:17 nC @ 4.5 V
- Vgs (Max):±5V
- Input Capacitance (Ciss) (Max) @ Vds:900 pF @ 4 V
- FET Feature:-
- Power Dissipation (Max):780mW (Ta), 1.8W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:4-Microfoot
- Package / Case:4-UFBGA
