APT130SM70J

Technical Details

• Series:-
• Package:Bulk
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:SiCFET (Silicon Carbide)
• Drain to Source Voltage (Vdss):700 V
• Current - Continuous Drain (Id) @ 25°C:78A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):20V
• Rds On (Max) @ Id, Vgs:45mOhm @ 60A, 20V
• Vgs(th) (Max) @ Id:2.4V @ 1mA

• Gate Charge (Qg) (Max) @ Vgs:270 nC @ 20 V
• Vgs (Max):+25V, -10V
• Input Capacitance (Ciss) (Max) @ Vds:3950 pF @ 700 V
• FET Feature:-
• Power Dissipation (Max):273W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Chassis Mount
• Supplier Device Package:SOT-227 (ISOTOP®)
• Package / Case:SOT-227-4, miniBLOC
