JANSR2N7389

Technical Details

• Series:Military, MIL-PRF-19500/630
• Package:Tray
• Part Status:Obsolete
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):100 V
• Current - Continuous Drain (Id) @ 25°C:6.5A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):12V
• Rds On (Max) @ Id, Vgs:350mOhm @ 6.5A, 12V
• Vgs(th) (Max) @ Id:4V @ 1mA

• Gate Charge (Qg) (Max) @ Vgs:45 nC @ 12 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:-
• FET Feature:-
• Power Dissipation (Max):25W (Tc)
• Operating Temperature:-55°C ~ 150°C
• Mounting Type:Through Hole
• Supplier Device Package:TO-205AF (TO-39)
• Package / Case:TO-205AF Metal Can
