TK12P60W,RVQ(S
Toshiba Electronic Devices and Storage Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 600V 11.5A DPAK
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 142
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:DTMOSIV
- Package:Tape & Reel (TR)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):600 V
- Current - Continuous Drain (Id) @ 25°C:11.5A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:340mOhm @ 5.8A, 10V
- Vgs(th) (Max) @ Id:3.7V @ 600µA
- Gate Charge (Qg) (Max) @ Vgs:25 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:890 pF @ 300 V
- FET Feature:-
- Power Dissipation (Max):100W (Tc)
- Operating Temperature:150°C
- Mounting Type:Surface Mount
- Supplier Device Package:DPAK
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
