SDM1M40LP8-7
Zetex Semiconductors (Diodes Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 40V 1A 2DFN
- CategoryDiodes - Rectifiers - Single
- Datasheet SDM1M40LP8-7 Datasheet
-
ECAD Model
- Share
In Stock: 12,096
Can ship immediately
Pricing:
- 1$0.4
- 10,000$0.08077
- 30,000$0.07615
- 50,000$0.07385
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):40 V
- Current - Average Rectified (Io):1A
- Voltage - Forward (Vf) (Max) @ If:660 mV @ 1 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):8.4 ns
- Current - Reverse Leakage @ Vr:20 µA @ 40 V
- Capacitance @ Vr, F:25pF @ 5V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:2-UFDFN
- Supplier Device Package:U-DFN1608-2
- Operating Temperature - Junction:-65°C ~ 150°C
