BAT750-7-F
Zetex Semiconductors (Diodes Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 40V 750MA SOT23-3
- CategoryDiodes - Rectifiers - Single
- Datasheet BAT750-7-F Datasheet
-
ECAD Model
- Share
In Stock: 1,744
Can ship immediately
Pricing:
- 1$0.41
- 3,000$0.09672
- 6,000$0.09188
- 15,000$0.08463
- 30,000$0.07979
- 75,000$0.07737
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):40 V
- Current - Average Rectified (Io):750mA
- Voltage - Forward (Vf) (Max) @ If:490 mV @ 750 mA
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):10 ns
- Current - Reverse Leakage @ Vr:100 µA @ 30 V
- Capacitance @ Vr, F:175pF @ 0V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:TO-236-3, SC-59, SOT-23-3
- Supplier Device Package:SOT-23-3
- Operating Temperature - Junction:-55°C ~ 125°C
