BAT54WS-HE3-18
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 30V 200MA SOD323
- CategoryDiodes - Rectifiers - Single
- Datasheet BAT54WS-HE3-18 Datasheet
-
ECAD Model
- Share
In Stock: 8,842
Can ship immediately
Pricing:
- 1$0.42
- 10,000$0.42
- 30,000$0.39824
- 50,000$0.37648
- 100,000$0.35471
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):30 V
- Current - Average Rectified (Io):200mA (DC)
- Voltage - Forward (Vf) (Max) @ If:800 mV @ 100 mA
- Speed:Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr):5 ns
- Current - Reverse Leakage @ Vr:2 µA @ 25 V
- Capacitance @ Vr, F:10pF @ 1V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:SC-76, SOD-323
- Supplier Device Package:SOD-323
- Operating Temperature - Junction:125°C (Max)
