SD103AWS-G3-18
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 350MA 40V SOD323
- CategoryDiodes - Rectifiers - Single
- Datasheet SD103AWS-G3-18 Datasheet
-
ECAD Model
- Share
In Stock: 3,603
Can ship immediately
Pricing:
- 1$0.45
- 10,000$0.07296
- 30,000$0.06898
- 50,000$0.06499
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):40 V
- Current - Average Rectified (Io):350mA (DC)
- Voltage - Forward (Vf) (Max) @ If:600 mV @ 200 mA
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):10 ns
- Current - Reverse Leakage @ Vr:5 µA @ 30 V
- Capacitance @ Vr, F:50pF @ 0V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:SC-76, SOD-323
- Supplier Device Package:SOD-323
- Operating Temperature - Junction:-55°C ~ 125°C
