SB01-05Q-TL-E
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 50V 100MA 3MCP
- CategoryDiodes - Rectifiers - Single
- Datasheet SB01-05Q-TL-E Datasheet
-
ECAD Model
- Share
In Stock: 268,672,128
Can ship immediately
Pricing:
- 1$0.45
- 3,000$0.10055
- 6,000$0.09523
- 15,000$0.08725
- 30,000$0.08193
- 75,000$0.07927
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):50 V
- Current - Average Rectified (Io):100mA
- Voltage - Forward (Vf) (Max) @ If:550 mV @ 100 mA
- Speed:Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr):10 ns
- Current - Reverse Leakage @ Vr:15 µA @ 25 V
- Capacitance @ Vr, F:4.4pF @ 10V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:SC-70, SOT-323
- Supplier Device Package:3-MCP
- Operating Temperature - Junction:-55°C ~ 125°C
