1N5817RLG
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 20V 1A AXIAL
- CategoryDiodes - Rectifiers - Single
- Datasheet 1N5817RLG Datasheet
-
ECAD Model
- Share
In Stock: 1,223,730,177
Can ship immediately
Pricing:
- 1$0.47
- 5,000$0.08424
- 10,000$0.07681
- 25,000$0.07186
- 50,000$0.06938
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):20 V
- Current - Average Rectified (Io):1A
- Voltage - Forward (Vf) (Max) @ If:450 mV @ 1 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:1 mA @ 20 V
- Capacitance @ Vr, F:-
- Mounting Type:Through Hole
- Package / Case:DO-204AL, DO-41, Axial
- Supplier Device Package:Axial
- Operating Temperature - Junction:-65°C ~ 125°C
