MBRD580TR
SMC Diode Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 80V 5A DPAK
- CategoryDiodes - Rectifiers - Single
- Datasheet MBRD580TR Datasheet
-
ECAD Model
- Share
In Stock: 1,482
Can ship immediately
Pricing:
- 1$0.48
- 2,500$0.15552
- 5,000$0.14733
- 12,500$0.13915
- 25,000$0.13506
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):80 V
- Current - Average Rectified (Io):5A
- Voltage - Forward (Vf) (Max) @ If:750 mV @ 5 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:1 mA @ 80 V
- Capacitance @ Vr, F:300pF @ 5V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package:DPAK
- Operating Temperature - Junction:-55°C ~ 150°C
