TSUP5M60SH S1G
TSC (Taiwan Semiconductor)
- Lifecycle status Active
- RoHS RoHS Compliant
- Description5A, 60V, SCHOTTKY RECTIFIER
- CategoryDiodes - Rectifiers - Single
-
ECAD Model
- Share
In Stock: 3,115
Can ship immediately
Pricing:
- 1$0.67048
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):60 V
- Current - Average Rectified (Io):5A (DC)
- Voltage - Forward (Vf) (Max) @ If:640 mV @ 5 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:200 µA @ 60 V
- Capacitance @ Vr, F:346pF @ 4V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:TO-277, 3-PowerDFN
- Supplier Device Package:SMPC4.6U
- Operating Temperature - Junction:-55°C ~ 175°C
