FFSD08120A
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- Description1200V 8A SIC SBD
- CategoryDiodes - Rectifiers - Single
- Datasheet FFSD08120A Datasheet
-
ECAD Model
- Share
In Stock: 1,847
Can ship immediately
Pricing:
- 1$6.06
- 2,500$3.34871
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Silicon Carbide Schottky
- Voltage - DC Reverse (Vr) (Max):1200 V
- Current - Average Rectified (Io):22.5A (DC)
- Voltage - Forward (Vf) (Max) @ If:1.75 V @ 8 A
- Speed:No Recovery Time > 500mA (Io)
- Reverse Recovery Time (trr):0 ns
- Current - Reverse Leakage @ Vr:200 µA @ 1200 V
- Capacitance @ Vr, F:538pF @ 1V, 100kHz
- Mounting Type:Surface Mount
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package:TO-252, (D-Pak)
- Operating Temperature - Junction:-55°C ~ 175°C
