VS-12TQ045-M3
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 45V 15A TO220AC
- CategoryDiodes - Rectifiers - Single
-
ECAD Model
- Share
In Stock: 1,193
Can ship immediately
Pricing:
- 1$1.2
- 1,000$0.5735
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):45 V
- Current - Average Rectified (Io):15A
- Voltage - Forward (Vf) (Max) @ If:710 mV @ 30 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:1.75 mA @ 45 V
- Capacitance @ Vr, F:900pF @ 5V, 1MHz
- Mounting Type:Through Hole
- Package / Case:TO-220-2
- Supplier Device Package:TO-220AC
- Operating Temperature - Junction:-55°C ~ 150°C
