S1G R3G
TSC (Taiwan Semiconductor)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE GEN PURP 400V 1A DO214AC
- CategoryDiodes - Rectifiers - Single
- Datasheet S1G R3G Datasheet
-
ECAD Model
- Share
In Stock: 453
Can ship immediately
Pricing:
- 1$0.35
- 1,800$0.0651
- 3,600$0.05872
- 5,400$0.05106
- 12,600$0.0434
- 45,000$0.04085
- 90,000$0.03829
- 180,000$0.03574
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):400 V
- Current - Average Rectified (Io):1A
- Voltage - Forward (Vf) (Max) @ If:1.1 V @ 1 A
- Speed:Standard Recovery >500ns, > 200mA (Io)
- Reverse Recovery Time (trr):1.5 µs
- Current - Reverse Leakage @ Vr:1 µA @ 400 V
- Capacitance @ Vr, F:12pF @ 4V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:DO-214AC, SMA
- Supplier Device Package:DO-214AC (SMA)
- Operating Temperature - Junction:-55°C ~ 175°C
