SMMBD914LT1G
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE GP 100V 200MA SOT23-3
- CategoryDiodes - Rectifiers - Single
- Datasheet SMMBD914LT1G Datasheet
-
ECAD Model
- Share
In Stock: 790
Can ship immediately
Pricing:
- 1$0.39
- 3,000$0.07079
- 6,000$0.06401
- 15,000$0.05724
- 30,000$0.05385
- 75,000$0.05046
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):100 V
- Current - Average Rectified (Io):200mA (DC)
- Voltage - Forward (Vf) (Max) @ If:1 V @ 10 mA
- Speed:Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr):4 ns
- Current - Reverse Leakage @ Vr:5 µA @ 75 V
- Capacitance @ Vr, F:4pF @ 0V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:TO-236-3, SC-59, SOT-23-3
- Supplier Device Package:SOT-23-3 (TO-236)
- Operating Temperature - Junction:-55°C ~ 150°C
