VS-C4PH3006L-N3
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE GEN PURP 600V 15A TO247AD
- CategoryDiodes - Rectifiers - Single
- Datasheet VS-C4PH3006L-N3 Datasheet
-
ECAD Model
- Share
In Stock: 542
Can ship immediately
Pricing:
- 1$2.27
- 25$1.91908
- 100$1.63506
- 500$1.34336
- 1,000$1.11307
- 2,500$1.07469
Quote It
Technical Details
- Series:FRED Pt®
- Package:Tube
- Part Status:Active
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):600 V
- Current - Average Rectified (Io):15A
- Voltage - Forward (Vf) (Max) @ If:1.9 V @ 15 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):50 ns
- Current - Reverse Leakage @ Vr:15 µA @ 600 V
- Capacitance @ Vr, F:-
- Mounting Type:Through Hole
- Package / Case:TO-247-3
- Supplier Device Package:TO-247AD
- Operating Temperature - Junction:-55°C ~ 175°C
