ES1HL R3G
TSC (Taiwan Semiconductor)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE GEN PURP 500V 1A SUB SMA
- CategoryDiodes - Rectifiers - Single
- Datasheet ES1HL R3G Datasheet
-
ECAD Model
- Share
In Stock: 184
Can ship immediately
Pricing:
- 1$0.42
- 1,800$0.11677
- 3,600$0.10303
- 5,400$0.09388
- 12,600$0.08472
- 45,000$0.08014
- 90,000$0.07556
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):500 V
- Current - Average Rectified (Io):1A
- Voltage - Forward (Vf) (Max) @ If:1.7 V @ 1 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):35 ns
- Current - Reverse Leakage @ Vr:5 µA @ 500 V
- Capacitance @ Vr, F:8pF @ 4V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:DO-219AB
- Supplier Device Package:Sub SMA
- Operating Temperature - Junction:-55°C ~ 150°C
