SS2PH9HM3_A/H
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 29V 2A DO220AA
- CategoryDiodes - Rectifiers - Single
- Datasheet SS2PH9HM3_A/H Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$0.51
- 3,000$0.15654
- 6,000$0.14821
- 15,000$0.13989
- 30,000$0.13572
Quote It
Technical Details
- Series:Automotive, AEC-Q101, eSMP®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):29 V
- Current - Average Rectified (Io):2A
- Voltage - Forward (Vf) (Max) @ If:800 mV @ 2 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:1 µA @ 29 V
- Capacitance @ Vr, F:65pF @ 4V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:DO-220AA
- Supplier Device Package:DO-220AA (SMP)
- Operating Temperature - Junction:-55°C ~ 175°C
