S8JCHR7G
TSC (Taiwan Semiconductor)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE GEN PURP 600V 8A DO214AB
- CategoryDiodes - Rectifiers - Single
- Datasheet S8JCHR7G Datasheet
-
ECAD Model
- Share
In Stock: 146
Can ship immediately
Pricing:
- 1$0.49
- 850$0.22864
- 1,700$0.20736
- 2,550$0.19141
- 5,950$0.18078
- 21,250$0.17546
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):600 V
- Current - Average Rectified (Io):8A
- Voltage - Forward (Vf) (Max) @ If:985 mV @ 8 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:10 µA @ 600 V
- Capacitance @ Vr, F:48pF @ 4V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:DO-214AB, SMC
- Supplier Device Package:DO-214AB (SMC)
- Operating Temperature - Junction:-55°C ~ 150°C
