RUR1S1560S9A
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE GEN PURP 600V 15A D2PAK
- CategoryDiodes - Rectifiers - Single
- Datasheet RUR1S1560S9A Datasheet
-
ECAD Model
- Share
In Stock: 187
Can ship immediately
Pricing:
- 1$1.66
- 800$1.4266
- 1,600$1.194
- 2,400$1.15524
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):600 V
- Current - Average Rectified (Io):15A
- Voltage - Forward (Vf) (Max) @ If:1.5 V @ 15 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):60 ns
- Current - Reverse Leakage @ Vr:100 µA @ 600 V
- Capacitance @ Vr, F:-
- Mounting Type:Surface Mount
- Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Supplier Device Package:TO-263-3
- Operating Temperature - Junction:-55°C ~ 175°C
