SD200SCU150A.T
SMC Diode Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPIV 150V IO 60A CHIP SIZE 200MIL
- CategoryDiodes - Rectifiers - Single
- Datasheet SD200SCU150A.T Datasheet
-
ECAD Model
- Share
In Stock: 203
Can ship immediately
Pricing:
- 1$3.432
- 20$1.65259
- 40$1.47553
- 100$1.32803
- 500$1.03288
- 1,000$0.85581
- 2,000$0.8263
Quote It
Technical Details
- Series:-
- Package:Tray
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):150 V
- Current - Average Rectified (Io):60A
- Voltage - Forward (Vf) (Max) @ If:920 mV @ 60 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:1.5 mA @ 150 V
- Capacitance @ Vr, F:1500pF @ 5V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:Die
- Supplier Device Package:Die
- Operating Temperature - Junction:-55°C ~ 200°C
