VS-120NQ045PBF
Vishay General Semiconductor – Diodes Division
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 45V 120A D-67
- CategoryDiodes - Rectifiers - Single
- Datasheet VS-120NQ045PBF Datasheet
-
ECAD Model
- Share
In Stock: 109
Can ship immediately
Pricing:
- 1$22.17
- 10$20.37922
- 25$19.53505
- 100$17.21192
- 250$16.36713
- 500$15.31116
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):45 V
- Current - Average Rectified (Io):120A
- Voltage - Forward (Vf) (Max) @ If:630 mV @ 120 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:10 mA @ 45 V
- Capacitance @ Vr, F:5200pF @ 5V, 1MHz
- Mounting Type:Chassis Mount
- Package / Case:D-67 HALF-PAK
- Supplier Device Package:D-67
- Operating Temperature - Junction:-
