ES15DLWHRVG
TSC (Taiwan Semiconductor)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE, SUPER FAST
- CategoryDiodes - Rectifiers - Single
- Datasheet ES15DLWHRVG Datasheet
-
ECAD Model
- Share
In Stock: 182
Can ship immediately
Pricing:
- 1$0.45
- 3,000$0.127
- 6,000$0.12081
- 15,000$0.11152
- 30,000$0.10532
- 75,000$0.10222
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):200 V
- Current - Average Rectified (Io):1.5A
- Voltage - Forward (Vf) (Max) @ If:950 mV @ 1.5 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):35 ns
- Current - Reverse Leakage @ Vr:1 µA @ 200 V
- Capacitance @ Vr, F:24pF @ 4V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:SOD-123W
- Supplier Device Package:SOD-123W
- Operating Temperature - Junction:-55°C ~ 150°C
