SD091SB150A.T
SMC Diode Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPIV 150V IO 7.5A CHIP SIZE 90MIL
- CategoryDiodes - Rectifiers - Single
- Datasheet SD091SB150A.T Datasheet
-
ECAD Model
- Share
In Stock: 203
Can ship immediately
Pricing:
- 1$0.9614
- 20$0.9614
- 40$0.86845
- 100$0.7599
- 500$0.5893
- 1,000$0.46524
- 2,000$0.43422
Quote It
Technical Details
- Series:-
- Package:Tray
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):150 V
- Current - Average Rectified (Io):7.5A
- Voltage - Forward (Vf) (Max) @ If:890 mV @ 7.5 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:250 µA @ 150 V
- Capacitance @ Vr, F:250pF @ 5V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:Die
- Supplier Device Package:Die
- Operating Temperature - Junction:-55°C ~ 175°C
