SD175SB45B.T
SMC Diode Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPIV 45V IO 30A CHIP SIZE 175MIL
- CategoryDiodes - Rectifiers - Single
- Datasheet SD175SB45B.T Datasheet
-
ECAD Model
- Share
In Stock: 233
Can ship immediately
Pricing:
- 1$2.145
- 20$1.75175
- 40$1.56406
- 100$1.40772
- 500$1.09486
- 1,000$0.90716
- 2,000$0.87587
Quote It
Technical Details
- Series:-
- Package:Tray
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):45 V
- Current - Average Rectified (Io):30A
- Voltage - Forward (Vf) (Max) @ If:640 mV @ 30 A
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):-
- Current - Reverse Leakage @ Vr:800 mA @ 45 V
- Capacitance @ Vr, F:1600pF @ 5V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:Die
- Supplier Device Package:Die
- Operating Temperature - Junction:-55°C ~ 175°C
