BAT46WS
Diotec Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSCHOTTKY SOD-323 100V 0.15A
- CategoryDiodes - Rectifiers - Single
-
ECAD Model
- Share
In Stock: 147
Can ship immediately
Pricing:
- 1$0.0396
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Active
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):100 V
- Current - Average Rectified (Io):150mA
- Voltage - Forward (Vf) (Max) @ If:450 mV @ 10 mA
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):6 ns
- Current - Reverse Leakage @ Vr:5 µA @ 75 V
- Capacitance @ Vr, F:10pF @ 0V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:SC-90, SOD-323F
- Supplier Device Package:SOD-323
- Operating Temperature - Junction:-55°C ~ 150°C
