RS2G-HF

Technical Details

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Diode Type:Standard
• Voltage - DC Reverse (Vr) (Max):400 V
• Current - Average Rectified (Io):2A
• Voltage - Forward (Vf) (Max) @ If:1.3 V @ 2 A
• Speed:Fast Recovery =< 500ns, > 200mA (Io)

• Reverse Recovery Time (trr):150 ns
• Current - Reverse Leakage @ Vr:5 µA @ 400 V
• Capacitance @ Vr, F:22pF @ 4V, 1MHz
• Mounting Type:Surface Mount
• Package / Case:DO-214AC, SMA
• Supplier Device Package:DO-214AC (SMA)
• Operating Temperature - Junction:-55°C ~ 150°C
