TSS70U RGG
TSC (Taiwan Semiconductor)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDIODE SCHOTTKY 70V 70MA 0603
- CategoryDiodes - Rectifiers - Single
- Datasheet TSS70U RGG Datasheet
-
ECAD Model
- Share
In Stock: 123
Can ship immediately
Pricing:
- 1$0.05597
- 20,000$0.05597
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)
- Part Status:Not For New Designs
- Diode Type:Schottky
- Voltage - DC Reverse (Vr) (Max):70 V
- Current - Average Rectified (Io):70mA
- Voltage - Forward (Vf) (Max) @ If:1 V @ 15 mA
- Speed:Small Signal =< 200mA (Io), Any Speed
- Reverse Recovery Time (trr):5 ns
- Current - Reverse Leakage @ Vr:100 nA @ 25 V
- Capacitance @ Vr, F:2pF @ 0V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:0201 (0603 Metric)
- Supplier Device Package:0603
- Operating Temperature - Junction:-65°C ~ 125°C
