BAV5004WSQ-7
Zetex Semiconductors (Diodes Inc.)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionHIVOLT SWITCHING DIODE BVR > 100
- CategoryDiodes - Rectifiers - Single
-
ECAD Model
- Share
In Stock: 133
Can ship immediately
Pricing:
- 1$0.05693
- 3,000$0.05693
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)
- Part Status:Active
- Diode Type:Standard
- Voltage - DC Reverse (Vr) (Max):400 V
- Current - Average Rectified (Io):300mA (DC)
- Voltage - Forward (Vf) (Max) @ If:1.29 V @ 200 mA
- Speed:Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):50 ns
- Current - Reverse Leakage @ Vr:1 µA @ 240 V
- Capacitance @ Vr, F:0.9pF @ 0V, 1MHz
- Mounting Type:Surface Mount
- Package / Case:SC-76, SOD-323
- Supplier Device Package:SOD-323
- Operating Temperature - Junction:-55°C ~ 150°C
